U1-01: Frequency Reference
U1-02: Output Frequency
U1-05: Motor Speed
U1-16: Output Frequency after Soft-Starter (Accel/Decel Ramp Generator)
d1-01 to d1-17: Frequency References
n
o1-05: LCD Contrast Control
Sets the brightness of the optional LCD operator. The lower the setting, the brighter the LCD contrast. The higher the setting,
the darker the LCD contrast.
No. Name Setting Range Default
o1-05 LCD Contrast Control 0 to 5 3
n
o1-06: User Monitor Selection Mode
Select between standard sequential monitors or selectable monitors to be displayed on the 2nd and 3rd lines of the digital
operator display.
Use parameters o1-07 and o1-08 to select and fix the second and third monitors shown in the Home (Frequency Reference)
and Monitor screen to ensure that those monitors are always visible when scrolling through the monitor list.
No. Name Setting Range Default
o1-06 User Monitor Selection Mode 0, 1 0
Setting 0: 3 Mon Sequential (displays the next 2 sequential monitors)
Setting 1: 3 Mon Selectable (set by o1-07 and o1-08)
n
o1-07: Second Line User Monitor Selection
Selects the monitor that is shown in the second line. Effective only when o1-06 is set to 1.
Enter the last three digits of the monitor parameter number to be displayed: Uo-oo. For example, set “403” to display
monitor parameter U4-03.
No. Name Setting Range Default
o1-07 Second Line User Monitor Selection 101 to 799 102
n
o1-08: Third Line User Monitor Selection
Selects the monitor that is shown in the third line. Effective only when o1-06 is set to 1.
Enter the last three digits of the monitor parameter number to be displayed: Uo-oo. For example, set “403” to display
monitor parameter U4-03.
No. Name Setting Range Default
o1-08 Second Line User Monitor Selection 101 to 904 191
5.10 o: Operator Related Settings
216
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
