B.15 T: Motor Tuning
Enter data into the following parameters to tune the motor and drive for optimal performance
u
T1: Induction Motor Auto-Tuning
No.
(Addr.
Hex)
Name LCD Display Description Values Page
T1-01
(0701)
Auto-Tuning Mode
Selection
Tuning Mode Sel
2: Term Resistance
2: Stationary Auto-Tuning for Line-to-Line Resistance Default: 2
Range: 2
102
T1-02
(0702)
Motor Rated Power Mtr Rated Power
Sets the motor rated power as specified on the motor nameplate.
Note: Use the following formula to convert horsepower
into kilowatts:
1HP = 0.746 kW.
Default:
<1>
Min.: 0.03 kW
Max.: 650.00
kW
103
T1-04
(0704)
Motor Rated Current Rated Current
Sets the motor rated current as specified on the motor
nameplate.
Default:
<1>
Min.: 10% of
drive rated
current
Max.: 200% of
drive rated
current
103
<1> Default setting is dependent on parameter o2-04, Drive Model Selection.
B.15 T: Motor Tuning
368
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
