4.7 Pump Application Presets
The following sections list the parameters affected by the different Application Presets.
u
Parameters Set Depending on A1-03 Setting
The following table shows the parameters that are set depending on the A1-03 initialization:
A1-03 = 6008
(A1-06 = 8)
Pressure Control
A1-03 = 6009
(A1-06 = 9)
Pump Down Level
A1-03 = 7770
(A1-06 = 1)
General Purpose
A1-03 = 7771
(A1-06 = 2)
Sub Mtr GP Oper
Parameter Value Parameter Value Parameter Value Parameter Value
b5-09 1 b1-01 1 b5-01 0
b5-39 2 b1-02 1 H1-06 4
P1-02 6 b5-01 0 H1-07 0
P2-01 2 C1-01 25.0 sec H2-02 0
P2-23 0.00% C1-02 25.0 sec H2-03 A
H1-06 4 o1-06 0
H1-07 F P1-05 0 sec
H2-02 0 d1-01 40.00 Hz
H2-03 A
H3-02 0
H3-10 2
L5-01 0
L5-04 180.0 sec
o1-06 0
P1-05 0 sec
P1-06 0.0 Hz
P4-12 0.0 Hz
P4-17 0.0 min
P5-02 0.0 Hz
u
Parameters Displayed Depending on A1-06 Setting
The following table shows which parameters are shown on the Pump Quick Setup menu depending on the A1-06 selection:
A1-03 = 6008
(A1-06 = 8)
Pressure Control
A1-03 = 6009
(A1-06 = 9)
Pump Down Level
A1-03 = 7770
(A1-06 = 1)
General Purpose
A1-03 = 7771
(A1-06 = 2)
Sub Mtr GP Oper
E2-01 E2-01 b1-01 E2-01
E2-04 E2-04 b1-02 E2-04
P1-03 P1-02 C1-01 d1-01
Q1-01 P1-03 C1-02 P1-06
P1-04 Q1-01 E2-01 P4-10
P1-06 P1-04 E2-04 P5-04
P4-10 P1-06 L5-01
P5-04 P2-02 L5-04
P4-10 P1-06
P5-04
4.7 Pump Application Presets
86
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
