6.6 Copy Function Related Displays
u
Tasks, Errors, and Troubleshooting
The table below lists the messages and errors that may appear when using the Copy function.
When executing the tasks offered by the Copy function, the keypad will indicate the task being performed. When an error
occurs, a code appears on the keypad to indicate the error. Note that errors related to the Copy function do not trigger a multi-
function output terminal that has been set up to close when a fault or alarm occurs. To clear an error, simply press any key on
the keypad and the error display will disappear.
Table 6.5 lists the corrective action that can be taken when an error occurs.
Note: 1. The drive should be fully stopped when using the copy function.
2. The drive will not accept a Run command while the Copy function is being executed.
3. Parameters can only be saved to a drive when the voltage class, capacity, control mode, and software version match.
Table 6.5 Copy Function Task and Error Displays
LED Display LCD Display Task
copy
CoPy
Writing Parameter Settings (flashing)
Cause Possible Solutions
Parameters are being written to the drive. This is not an error.
LED Display LCD Display Task
cpye
CoPyE
Error Writing Data
Cause Possible Solutions
Failed writing parameters Attempt to write parameters again.
LED Display LCD Display Task
c5er
CSEr
Copy Unit Error
Cause Possible Solutions
Hardware fault Replace the HOA keypad or the USB Copy Unit.
LED Display LCD Display Task
dfp5
dFPS
Drive Model Mismatch
Cause Possible Solutions
The drives used in the copy and write process
are not the same model.
• The drive from which the parameters were
copied is a different model.
• The drive to be written to is a different
model.
• Verify the model number of the drive from which the parameters were copied and the model of the drive
to which those parameters will be written.
• Make sure the two drives are the same model and have the same software version.
LED Display LCD Display Task
end
End
Task Complete
Cause Possible Solutions
Finished reading, writing, or verifying
parameters.
This is not an error.
LED Display LCD Display Task
ifer
iFEr
Communication Error
Cause Possible Solutions
A communication error occurred between
the drive and the HOA keypad or the USB
copy unit.
Check the cable connection.
A non-compatible cable is being used to
connect the USB Copy Unit and the drive.
Use the cable originally packaged with the USB Copy Unit.
6.6 Copy Function Related Displays
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
283
6
Troubleshooting
