7.4 Drive Cooling Fans
NOTICE: Follow cooling fan replacement instructions. The cooling fan cannot operate properly when installed incorrectly and could seriously
damage the drive. To ensure maximum useful product life, replace all cooling fans when performing maintenance.
Contact your Yaskawa representative or supplier to order replacement cooling fans as required.
Some drive models have multiple cooling fans.
For drives with multiple cooling fans, replace all the fans when performing maintenance to ensure maximum useful product
life.
u
Number of IP20/NEMA 1, UL Type 1 Cooling Fans
Drive Model Cooling Fans
Single-Phase 200 V Class
BV0006F –
BV0010F 1
BV0012F 1
BV0018F 2
Three-Phase 200 V Class
2V0006F 1
2V0010F 1
2V0012F 1
2V0020F 1
2V0030F 2
2V0040F 2
2V0056F 2
2V0069F 2
Three-Phase 400 V Class
4V0002F –
4V0004F –
4V0005F 1
4V0007F 1
4V0009F 1
4V0011F 1
4V0018F 2
4V0023F 2
4V0031F 2
4V0038F 2
7.4 Drive Cooling Fans
294
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
