YASKAWA iQpump Micro CIMR-PW Series

A.3 Drive Watt Loss Data
Table A.6 Watt Loss 200 V Class Single-Phase Models
Drive Model
Normal Duty (Swing PWM equal 2 kHz)
Rated Amps (A) Heatsink Loss (W) Interior Unit Loss (W) Total Loss (W)
BV0006 6.0 30.1 19.4 49.5
BV0010 9.6 51.7 29.8 81.4
BV0012 12.0 61.3 37.1 98.4
BV0018 17.5 110.5 51.4 161.9
Table A.7 Watt Loss 200 V Class Three-Phase Models
Drive Model
Normal Duty (Swing PWM equal 2 kHz)
Rated Amps (A) Heatsink Loss (W) Interior Unit Loss (W) Total Loss (W)
2V0006 6.0 27.5 17.2 44.7
2V0010 9.6 51.7 25.8 77.5
2V0012 12.0 61.3 30.4 91.7
2V0020 19.6 98.7 46.3 145.0
2V0030 30.0 246.4 88.9 335.3
2V0040 40.0 266.7 112.8 379.6
2V0056 56.0 357.9 151.8 509.7
2V0069 69.0 461.7 184.5 646.2
Table A.8 Watt Loss 400 V Class Three-Phase Models
Drive Model
Normal Duty (Swing PWM equal 2 kHz)
Rated Amps (A) Heatsink Loss (W) Interior Unit Loss (W) Total Loss (W)
4V0002 2.1 18.5 13.9 32.4
4V0004 4.1 30.5 16.8 47.3
4V0005 5.4 44.5 21.8 66.3
4V0007 6.9 58.5 28.4 86.9
4V0009 8.8 63.7 31.4 95.1
4V0011 11.1 81.7 46.0 127.7
4V0018 17.5 181.2 80.1 261.3
4V0023 23.0 213.4 107.7 321.1
4V0031 31.0 287.5 146.1 433.6
4V0038 38.0 319.2 155.8 475.0
A.3 Drive Watt Loss Data
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
313
A
Specifications
