B.1 Parameter Groups
Parameter
Group
Name Page
A1 Initialization 319
A2 User Parameters 319
b1 Operation Mode Selection 320
b2 DC Injection Braking 321
b3 Speed Search 321
b4 Delay Timer 322
b5 PID Control 322
b6 Dwell Function 324
C1 Acceleration/Deceleration Time 325
C2 S-Curve Accel/Decel 325
C3 Motor Slip Compensation 326
C4 Motor Torque Compensation 326
C6 Carrier Frequency 326
d1 Frequency Reference 327
d2 Reference Limits 328
d3 Jump Frequencies 328
d4 Frequency Reference Hold 329
E1 V/f Pattern 330
E2 Motor Setup 331
F6 Network Communications 333
F7
EtherNet/IP and Modbus TCP/IP
Communications
333
H1 Digital Inputs 335
H2 Digital Outputs 339
H3 Analog Inputs 341
H4 Analog Outputs 343
H5 Serial Communications Setup 343
H6 Pulse Train I/O Setup 344
L1 Motor Overload 345
L2 Power Loss Ride-Thru 346
Parameter
Group
Name Page
L3 Stall Prevention 346
L4 Reference Detection 348
L5 Fault Restart 348
L6 Overtorque Detection 349
L8 Hardware Protection 350
n1 Hunting Prevention 352
n3 High-Slip Braking 352
o1 Monitor Display Selection 353
o2 Operator Keypad Functions 354
o3 Copy Function 354
o4 Maintenance Functions 355
P1 Pump Basic 356
P2 Pump Protection 358
P4 Pump Advanced 359
P5 Pump HAND Mode 361
P7 Anti-Jam 362
P9 Network Options 362
Q1 Preset Setpoint 366
Q3 Output Current Limit 366
S6 Protection 367
T1 Auto-Tuning 368
U1 Status Monitor 369
U2 Fault Trace 372
U3 Fault History 372
U4 Maintenance Monitor 374
U5 PID Monitor 376
U6 Control Monitor 376
U9 Operation Status Monitors 376
B.1 Parameter Groups
318
