No.
(Addr.
Hex)
Name LCD Display Description Values Page
P5-05
(0D30)
HAND Reference 2 HAND Reference 2
Sets the frequency reference used when HAND Mode 2 is
active.
Default: 0.0 Hz
Min.: 0.0
Max.: [E1-04]
236
P5-06
(0D31)
HAND Ref. 1 Loss of
Prime Level
HandRef1 LOP Lvl
Detects loss of prime in the pump when in HAND Mode.
When the measured quantity determined by P1-18 drops below
this level for the time set in P1-20 and the output frequency is
at the level set in P5-02, a “Loss of Prime” condition occurs.
The drive responds to the “Loss of Prime” condition depending
on the setting of P1-22, Loss of Prime Selection.
Default: 0.0 A
<1>
Min.: 0.0
Max.: 1000.0
236
P5-07
(0D32)
HAND Ref. 2 Loss of
Prime Level
HandRef2 LOP Lvl
Detects loss of prime in the pump when in HAND Mode 2.
When the measured quantity determined by P1-18 drops below
this level for the time set in P1-20 and the output frequency is
at the level set in P5-05, a “Loss of Prime” condition occurs.
The drive responds to the “Loss of Prime” condition depending
on the setting of P1-22, Loss of Prime Selection.
Default: 0.0 A
<1>
Min.: 0.0
Max.: 1000.0
236
P5-09
(0D34)
HAND References Set
via Motor Operated Pot
Selection
HAND MOP Sel
0: Disabled
1: Enabled
Selects whether parameters P5-02 and P5-05 are changed via
MOP from the home screen.
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
236
<1> Unit text is set by P1-18, Prime Loss Detection Method.
u
P7: Anti-Jam
No.
(Addr.
Hex)
Name LCD Display Description Values Page
P7-01
(0D90)
Anti-Jam Operation
Selection
Anti-Jam Sel
0: Disabled
1: Enabled
Enables and disables the anti-jam function.
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
237
P7-02
(0D91)
Anti-Jam Cycle Count AJ Cycle Count
Sets the maximum number of cycles that will be attempted
before triggering and Anti-Jam fault.
Default: 1
Min.: 1
Max.: 100
237
P7-03
(0D92)
Anti-Jam Detection
Current Level
AJ Det I @Start
Sets the current level at start that will trigger the anti-jam
function.
Set as a percentage of the motor rated current.
Default: 120%
Min.: 50
Max.: 200
237
P7-04
(0D93)
Anti-Jam Detection
Time at Start
AJ Det Tm@Start
Sets the length of time that current must rise above the level set
in P7-03 to trigger the anti-jam function.
Default: 0.3 s
Min.: 0.1
Max.: 2.0
237
P7-05
(0D94)
Anti-Jam During Run
Current
AJ Det I @Run
Sets the current level during run that will trigger the anti-jam
function.
Set as a percentage of motor rated current.
Setting this parameter to 0 will disable anti-jam during run.
Default: 0%
Min.: 0
Max.: 200
237
P7-06
(0D95)
Anti-Jam During Run
Time
AJ Det Tm @Run
Sets the length of time that the current must rise above the level
set in P7-05 to trigger the anti-jam function.
Restricted to simplex only.
Default: 0.3 s
Min.: 0.1
Max.: 2.0
237
P7-07
(0D96)
Anti-Jam Frequency
Reference
AJ Freq Ref
Sets the maximum speed allowed when the anti-jam function is
active.
Default: 25.00
Hz
Min.: 0.00
Max.: 400.00
237
P7-08
(0D98)
Anti-Jam Release Time AJ Release Time
Sets the length of time that the current must fall below the level
set in P7-03 to resume normal operation.
Default: 2.0 s
Min.: 0.5
Max.: 10.0
237
u
P9: Network Options
Parameters in this group are functional only when P1-01, Pump Mode, is set to 3 (MEMOBUS network).
B.12 P: Pump Parameters
