Switching from AUTO to HAND is not permitted when the drive it running in Modbus multiplex mode with auxiliary drives
enabled.
No. Name Setting Range Default
P5-03 HAND/AUTO during Run Selection 0, 1 0
Setting 0: Disabled
Setting 1: Enabled
n
P5-04: HAND Key Function Selection
Selects whether the HAND key on the HOA keypad is active. Disabling this function by setting P5-04 to 0 will prevent the
drive from entering HAND Mode.
No. Parameter Name Setting Range Default
P5-04 HAND Key Function Selection 0, 1 1
Setting 0: Disabled
Setting 1: Enabled
n
P5-05: HAND Reference 2
Sets the frequency reference used when Hand Mode 2 is active.
No. Name Setting Range Default
P5-05 HAND Reference 2 0.0 to [E1-04] 0.0 Hz
n
P5-06: HAND Reference 1 Loss of Prime Level
Sets the level used to detect loss of prime in the pump.
No. Name Setting Range Default
P5-06 HAND Reference 1 Loss of Prime Level 0.0 to 1000.0 0.0 A
If the measured quantity set in P1-18 drops below this level for the time specified in P1-20 and the output frequency is at or
above the P5-02 level, a “Loss Of Prime” condition occurs. The drive will respond to the “Loss Of Prime” condition based
on P1-22 setting.
n
P5-07: HAND Reference 2 Loss of Prime Level
Sets the level used to detect loss of prime in the pump.
No. Name Setting Range Default
P5-07 HAND Reference 2 Loss of Prime Level 0.0 to 1000.0 0.0 A
If the measured quantity set in P1-18 drops below this level for the time specified in P1-20 and the output frequency is at or
above the P5-02 level, a “Loss Of Prime” condition occurs. The drive will respond to the “Loss Of Prime” condition based
on P1-22 setting.
n
P5-09: HAND References Set via Motor Operated Pot Selection
Selects whether parameters P5-02 and P5-05 are changed via MOP (up and down arrow keys) on the HOA keypad.
No. Name Setting Range Default
P5-09 HAND References Set via Motor Operated Pot Selection 0, 1 0
Setting 0: Disabled
Setting 1: Enabled
u
P7: Anti-Jam
Anti-Jam is a method to detect and attempt to expel solids that preventing the pump impeller from turning.
The drive monitors the output current when starting from zero speed. When the current goes too high, the motor will coast to
stop and switch into reverse. This cycle is repeated until the output current remains below the detection level or until the drive
faults out on an “AJF – Anti-Jam Fault”.
WARNING! Sudden Movement Hazard. The Anti-Jam function can force the motor to briefly run in the reverse direction and may cause
injury even if parameter b1-04 is set to “Reverse Disabled”. Be sure all personnel are clear of rotating machinery.
5.11 P: Pump
236
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
