A.4 Drive Derating Data
The drive can be operated at above the rated temperature, altitude, and default carrier frequency by derating the drive capacity.
u
Single-Phase Derating
iQpump Micro drives are compatible for use with both three-phase and single-phase input power supplies. The drive output
to the motor is always three-phase, regardless of number of input phases.
Output capacity to the motor is derated when using single-phase input power and the drive firmware includes protection for
single-phase input applications. This protection is enabled by default. Disabling this protection for single-phase input
applications can void warranty and result in premature failure.
Selection of larger models always results in greater output capacity to the motor when supplying the drive with three-phase
input power. However, the selection of larger models does not always yield greater output capacity when using the drive with
single-phase input power.
Several factors affect the amount of derated drive output capacity when single-phase input power is supplied to the drive:
• Single-phase input voltage level
• Motor voltage rating
• Amount of input impedance.
The tables in this section assist in model selection by considering factors that affect the amount of derating in single-phase
input power applications.
n
Single-Phase Input Sizing
The rated output current listed in the tables allows for a 120% overload for 60 seconds. Contact Yaskawa if assistance is needed
in selecting drive models with higher overload requirements. Adding more impedance than is specified will degrade
performance.
Table A.9 240 V Single-Phase Input (-5% to +10%)
Drive Model
Without Input Reactor With Input Reactor
Rated Input
Current (A)
Rated
Output
Current (A)
Max
Applicable
Motor (HP)
Yaskawa Reactor Part
Number
Rated Input
Current (A)
Rated
Output
Current (A)
Max
Applicable
Motor (HP)
2V0006 7.3 4.9 1.0 URX000303 7.3 4.9 1.0
2V0010 10.8 6.8 1.5 URX000307 10.8 6.8 1.5
2V0012 13.9 7.5 2.0 URX000311 13.9 7.5 2.0
2V0020 24.0 9.7 2.0 URX000319 24.0 12.3 3.0
2V0030 37.0 7.5 2.0 URX000326 37.0 15.2 3.0
2V0040 52.0 16.7 5.0 URX000329 52.0 21.0 5.0
2V0056 68.0 23.4 5.0 URX000335 68.0 27.7 7.5
2V0069 80.0 25.8 7.5 URX000335 80.0 30.8 10.0
Table A.10 480 V Single-Phase Input (-5% to +10%)
Drive Model
Without Input Reactor With Input Reactor
Rated Input
Current (A)
Rated
Output
Current (A)
Max
Applicable
Motor (HP)
Yaskawa Reactor Part
Number
Rated Input
Current (A)
Rated
Output
Current (A)
Max
Applicable
Motor (HP)
4V0002 2.1 1.3 0.5 URX000292 2.1 1.7 0.5
4V0004 4.3 2.4 1.0 URX000300 4.3 2.8 1.0
4V0005 5.9 3.5 1.5 URX000304 5.9 3.9 2.0
4V0007 8.1 3.5 1.5 URX000309 8.1 5.4 2.0
4V0009 9.4 5.1 2.0 URX000308 9.4 5.5 3.0
4V0011 14.0 5.5 3.0 URX000312 14.0 7.5 3.0
4V0018 20.0 4.5 2.0 URX000316 20.0 8.7 5.0
4V0023 24.0 5.5 3.0 URX000320 24.0 10.5 5.0
4V0031 38.0 7.9 3.0 URX000327 38.0 13.5 7.5
4V0038 44.0 11.3 5.0 URX000327 44.0 16.1 10.0
