YASKAWA iQpump Micro CIMR-PW Series

No.
(Addr.
Hex)
Name LCD Display Description Values Page
d1-14
(028F)
Frequency Reference 14 Reference 14
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 3, 4" (H1-oo = 3, 5, 32) are on.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
147
d1-15
(0290)
Frequency Reference 15 Reference 15
Frequency reference when digital inputs "Multi-Step Speed
Reference 2, 3, 4" (H1-oo = 4, 5, 32) are on.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
147
d1-16
(0291)
Frequency Reference 16 Reference 16
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 2, 3, 4" (H1-oo = 3, 4, 5, 32) are on.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
147
d1-17
(0292)
Jog Frequency
Reference
Jog Reference
Frequency reference when digital inputs "Jog Frequency
Reference", "Forward Jog", or "Reverse Jog." are on. "Jog
Frequency Reference" has priority over "Multi-Step Speed
Reference 1 to 16”.
Default: 6.00 Hz
Min.: 0.00
Max.: 400.00
<1>
147
<1> Range upper limit is determined by parameters d2-01, Frequency Reference Upper Limit, and E1-04, Maximum Output Frequency.
u
d2: Frequency Upper/Lower Limits
No.
(Addr.
Hex.)
Name LCD Display Description Setting Page
d2-01
(0289)
Frequency Reference
Upper Limit
Ref Upper Limit
Sets the frequency reference upper limit as a percentage of the
maximum output frequency.
Default: 100.0%
Min.: 0.0
Max.: 110.0
148
d2-02
(028A)
Frequency Reference
Lower Limit
Ref Lower Limit
Sets the frequency reference lower limit as a percentage of the
maximum output frequency.
Default: 0.0%
Min.: 0.0
Max.: 110.0
148
d2-03
(0293)
Master Speed Reference
Lower Limit
Ref1 Lower Limit
Sets the lower limit for frequency references from analog inputs
as a percentage of the maximum output frequency.
Default: 0.0%
Min.: 0.0
Max.: 110.0
149
u
d3: Jump Frequency
No.
(Addr.
Hex)
Name LCD Display Description Values Page
d3-01
(0294)
Jump Frequency 1 Jump Freq 1
Eliminates problems with resonant vibration of the motor/
machine by avoiding continuous operation in predefined
frequency ranges. The drive accelerates and decelerates the
motor through the prohibited frequency ranges.
Parameters must be set so that d3-01 ≥ d3-02 ≥ d3-03.
Setting this parameter to 0.0 disables the function.
Default: 0.0 Hz
Min.: 0.0
Max.: 400.0
149
d3-02
(0295)
Jump Frequency 2 Jump Freq 2
Default: 0.0 Hz
Min.: 0.0
Max.: 400.0
149
d3-03
(0296)
Jump Frequency 3 Jump Freq 3
Default: 0.0 Hz
Min.: 0.0
Max.: 400.0
149
d3-04
(0297)
Jump Frequency Width Jump Bandwidth
Sets the dead-band width around each selected prohibited
frequency reference point.
Default: 1.0 Hz
Min.: 0.0
Max.: 20.0
149
B.5 d: References
328
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
