No.
(Addr.
Hex)
Name LCD Display Description Values Page
o1-10
(0520)
User-Set Display Units
Maximum Value
UserDisp Scaling
These settings define the display values when o1-03 is set to 3.
o1-10 sets the display value that is equal to the maximum output
frequency.
o1-11 sets the position of the decimal position.
Default:
<1>
Range: 1 to
60000
217
o1-11
(0521)
User-Set Display Units
Decimal Display
UserDisp Dec
Default:
<1>
Range: 0 to 3
217
o1-12
(0522)
Home Help Text
Top Help on Home
0: Disabled
1: Enabled
Switches the top line of the Home Screen from the Drive Status
to defined Help messages.
0: Disabled
1: Enabled
Default: 1
Range: 0, 1
217
<1> Default setting is dependent on parameter o1-03, Digital Operator Display Selection.
u
o2: HOA Keypad Keypad Functions
No.
(Addr.
Hex)
Name LCD Display Description Values Page
o2-02
(0506)
STOP Key Function
Selection
Oper STOP Key
0: Disabled
1: Enabled
0: Disabled. STOP key is disabled in REMOTE operation.
1: Enabled. STOP key is always enabled.
Default: 1
Range: 0, 1
217
o2-03
(0507)
User Parameter Default
Value
User Default Sel
0: No Change
1: Save User Init
2: Clear User Init
0: No change.
1: Set defaults. Saves parameter settings as default values for a
User Initialization.
2: Clear all. Clears the default settings that have been saved for
a User Initialization.
Default: 0
Range: 0 to 2
218
o2-04
(508)
Drive Model Selection Inverter Model #
Enter the drive model. Setting required only if installing a new
control board.
Default:
Determined by
drive capacity
218
o2-05
(0509)
Frequency Reference
Setting Method
Selection
Oper Ref Method
0: Disabled
1: Enabled
0: ENTER key must be pressed to enter a frequency reference.
1: ENTER key is not required. The frequency reference can be
adjusted using the up and down arrow keys only.
Default: 0
Range: 0, 1
218
o2-06
(050A)
Operation Selection
when Digital Operator is
Disconnected
Oper Discon Det
0: Disabled
1: Enabled
0: The drive continues operating if the digital operator is
disconnected.
1: An oPr fault is triggered and the motor coasts to stop.
Default: 0
Range: 0, 1
219
o2-07
(0527)
Motor Direction at
Power Up when Using
Operator
For/RevSel@PwrUp
0: Forward
1: Reverse
This parameter requires assigning drive operation to the digital
operator.
0: Forward
1: Reverse
Default: 0
Range: 0, 1
219
o2-30
(1230)
Monitor Position Save
Mon Pos Save
0: Disabled
1: Enabled
Saves the monitor position and Home Screen quick monitor
selection.
Setting this parameter to 0 and then entering the Monitor Menu
will jump the selection to the monitor number instead of the
group number.
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
219
u
o3: Copy Function
No.
(Addr.
Hex)
Name LCD Display Description Values Page
o3-01
(0515)
Copy Function
Selection
COPY SELECT
0: COPY SELECT
1: INV→OP READ
2: OP→INV WRITE
3: OP←→INV
VERIFY
0: No action
1: Read parameters from the drive, saving them onto the digital
operator.
2: Copy parameters from the digital operator, writing them to
the drive.
3: Verify parameter settings on the drive to check if they match
the data saved on the operator.
Default: 0
Range: 0 to 3
219
o3-02
(0516)
Copy Allowed Selection
Read Allowable
0: Disabled
1: Enabled
0: Read operation prohibited
1: Read operation allowed
Default: 1
Range: 0, 1
220
B.11 o: Operator Related Parameters
354
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
