H2-oo
Setting
Function LCD Display Description Page
4E
Braking transistor fault
(rr)
Brk Trans Fault
Closed: The built-in dynamic braking transistor failed.
181
4F
Braking resistor
overheat (oH)
BrkResistOvHeat
Closed: The dynamic braking resistor has overheated.
181
58 Underload detection UL6 Closed: Underload is detected. 181
89 Output I Limit Output I Lim
Closed: Drive output speed is being limited due to the output current limit or the
single phase foldback regulator.
181
8B
Lube Pump or Digital
Output Delay
Lube Pump or
DigitalOutput Delay
Closed: Refer to Lube Pump / Digital Output Delay parameters P4-30 and P4-31.
Display text is set by parameter P4-29.
181
8F Internal Fan On Internal Fan On Internal Fan On 181
91 Pump Fault Pump Fault
Closed when any of the following faults are active:
• Low feedback
• High feedback
• Low water
• High water
• NMS-Setpoint not met
• POC-Pump over cycle
• THMS-Thermostat input
• External pump fault
181
92 Transducer Loss Transducer Loss
Closed: The analog output associated with PID feedback has risen above 21 mA
or fallen below 3 mA or a Transducer Loss alarm or fault is active.
181
93 Setptoint Not Met SetPoint Not Met Closed: During an “NMS-Setpoint Not Met” condition. 181
94 Loss of Prime Loss of Prime Closed: During an “LOP-Loss of Prime” condition. 181
95 Volute Thermostat Fault Volute-TStat Flt Closed: Volute-Thermostat digital input is active. 181
96 High Feedback High Feedback
Closed: During a “High Feedback” condition as defined by P1-11 and P1-14 OR
Closed: During a “High FB/Water” fault OR
Closed: During a “High Feedback” alarm
182
97 Low Feedback Low Feedback
Closed: During a “Low Feedback” condition as defined by P1-08 and P1-14 OR
Closed: During a “Low FB/Water” fault OR
Closed: During a “Low Feedback” alarm
182
A2 Sleep Active Sleep Active
Closed: The drive is not running due to the Sleep function (does not include Sleep
Boost).
182
A3 Start Delay Start Delay
Closed: Feedback has risen above the start level (or fallen below for Inverse PID)
and the start timer is timing.
182
A4 Pre-Charge Pre-Chg Active Closed: Drive is in Pre-Charge mode. 182
A5 Anti-Jam Active Anti-Jam Active
Closed: The anti-jam function is active (configured by P7-oo).
182
A9 Thrust Mode Thrust Mode
Closed: The Thrust Bearing feature is active (output frequency is between 0 and
the value of P4-12).
182
AA Utility Start Delay Utility Delay
Closed: The drive is stopped and waiting for the utility delay timer set in P4-17 to
expire.
182
100 to
1AA
Function 0 to AA with
inverse output
–
Inverts the output switching of the multi-function output functions.
Set the last two digits of 1oo to reverse the output signal of that specific function.
182
u
H3: Multi-Function Analog Inputs
No.
(Addr.
Hex)
Name LCD Display Description Values Page
H3-01
(0410)
Terminal A1 Signal
Level Selection
Term A1 Level
0: 0-10V,
(LowLim=0)
1: 0-10V, (BipolRef)
0: 0 to 10 V
1: -10 to 10 V Default: 0
Range: 0, 1
182
H3-02
(0434)
Terminal A1 Function
Selection
Term A1 FuncSel
Sets the function of terminal A1. Default: 0
Range: 0 to 41
183
H3-03
(0411)
Terminal A1 Gain
Setting
Terminal A1 Gain
Sets the level of the input value selected in H3-02 when 10 V is
input at terminal A1.
Default: 100.0%
Min.: -999.9
Max.: 999.9
183
B.8 H Parameters: Multi-Function Terminals
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
341
B
Parameter List
