T1-02: Motor Rated Power
Used to set the motor rated power according to the motor nameplate value. For optimal performance, the motor rated power
should be between 50 and 100% of the drive rating.
No. Name Setting Range Default
T1-02 Motor Rated Power
<1>
Determined by
o2-04 and C6-01
<1> The setting range differs based on drive software version.
PRG: 1016 and later: 0.03 to 650.00 kW
PRG: 1015 and earlier: 0.00 to 650.00 kW
n
T1-04: Motor Rated Current
Used to set the motor rated current according to the motor nameplate value. For optimal performance in OLV, the motor rated
current should be between 50 and 100% of the drive rating. Enter the current at the motor base speed.
No. Name Setting Range Default
T1-04 Motor Rated Current
10 to 200% of drive rated
current
Determined by
o2-04 and C6-01
4.9 Auto-Tuning
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
103
4
Start-Up Programming
& Operation
