1.2 Model Number and Nameplate Check
Please perform the following tasks after receiving the drive:
• Inspect the drive for damage.
If the drive appears damaged upon receipt, contact the shipper immediately.
• Verify receipt of the correct model by checking the information on the nameplate.
• If you have received the wrong model or the drive does not function properly, contact your supplier.
u
Nameplate
IND.CONT.EQ.
7J48
PASS
:
: AC3PH 200-240V 50 / 60Hz 2.7A
: AC3PH 0-240V 0-400Hz 1.2A / 0.8A
: 0.6 kg
:
:
: E131457 IP20
MODEL
MAX APPLI. MOTOR : 0.75kW / 0.4kW REV : A
INPUT
OUTPUT
MASS
O / N
S / N
FILE NO
I
H
G
F
D
B
A
YASKAWA ELECTRIC CORPORATION MADE IN JAPAN
2-1 Kurosaki-shiroishi, Yahatanishi-Ku, Kitakyushu 806-0004 Japan
C
E
CIMR-PW
A – Normal Duty Amps
B – Software version
C – Enclosure type
D –
Address
<1>
E – Serial number
F – Lot number
G – Output specifications
H – Input specifications
I – AC drive model
Figure 1.1 Nameplate Information Example
<1> The address of the head office of Yaskawa Electric Corporation (responsible for product liability) is shown on the nameplate.
CIMR
-
PW 2 V 0010 F A A
Drive
iQpump
No.
Enclosure
Type <1>
Design
Revision
Order
No.
Customized
Specifications
V Standard model
F
IP20/NEMA 1
UL Type 1
No.
Environmental
Specification <2>
A Standard
Refer to the following tables
G
IP66/NEMA 4X
UL Type 4X
No. Voltage Class
2
4
1-phase, 200-240 Vac
B
3-phase, 200-240 Vac
3-phase, 380-480 Vac
<1> Refer to Mechanical Installation on page 28 for differences regarding enclosure protection types and component
descriptions.
<2> Please contact Yaskawa for details regarding Environmental Specifications.
1.2 Model Number and Nameplate Check
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
23
1
Receiving
