YASKAWA iQpump Micro CIMR-PW Series

4-M6
W1
W
D
E
B
A
6- 28
H1
H2
H
t1
Voltage Class Drive Model
Dimensions mm (in)
W H D W1 H1 H2 t1 A B E
Wt.
kg (lb.)
Three-Phase
200 V Class
2V0010G
187
(7.36)
255
(10.04)
235
(9.25)
158
(6.22)
241
(9.49)
7
(0.28)
2.5
(0.10)
140
(5.51)
188
(7.40)
100
(3.94)
7.7
(16.98)
2V0012G
2V0020G
8.1
(17.86)
Three-Phase
400 V Class
4V0005G
187
(7.36)
255
(10.04)
235
(9.25)
158
(6.22)
241
(9.49)
7
(0.28)
2.5
(0.10)
140
(5.51)
188
(7.40)
100
(3.94)
7.7
(16.98)
4V0007G
7.9
(17.42)
4V0009G
4V0011G
8.1
(17.86)
2.2 Mechanical Installation
34
