No.
(Addr.
Hex)
Name LCD Display Description Values Page
P1-11
(0C0A)
High Feedback Level High FB Level
Sets the upper detection level for the PID feedback.
Note: When P1-03 is set to 3, parameter P9-18 uses the
value set here to calculate quick de-stage
feedback level.
Default: 155.0
PSI
<2>
Min.: 0.0
Max.: 6000.0
225
P1-12
(0C0B)
High Feedback Level
Fault Delay Time
High Lvl FLT Time
Sets the amount of delay time from when the high feedback is
detected until the drive faults on a “HFB High Feedback” fault.
Note: This parameter is effective only when P1-13 is set
to 0 (Fault (and digital out)).
Default: 5 s
Min.: 0
Max.: 3600
225
P1-13
(0C0C)
High Feedback
Selection
High FB Sel
0: Fault
1: Alarm
2: Digital Output
Selects drive response during the “High Feedback” condition.
0: Fault
1: Alarm
2: Digital out only
Default: 0
Range: 0 to 2
225
P1-14
(0C0D)
Hysteresis Level Hysteresis Level
Sets the hysteresis level used for low and high level feedback
detection.
Default: 0.0 PSI
<2>
Min.: 0.0
Max.: 100.0
226
P1-15
(0C0E)
Maximum Setpoint
Difference
Max Set Pnt Diff
Sets the level that the difference between the setpoint and the
feedback must exceed for the time set in P1-16 to trigger the
drive response set in P1-17.
If P1-17 is set to 1 (Fault and digital out), the drive will coast to
stop.
This function is active when the drive is running during AUTO
Mode. When P1-01 is set to 3 (MEMOBUS network), the
function is active on the lead drive and will stop all drives
running on the network when the NMS fault occurs.
Setting this parameter to 0.0 disables the function.
Default: 0.0 PSI
<2>
Min.: 0.0
Max.: 6000.0
226
P1-16
(0C0F)
Not Maintaining
Setpoint Time
Not Maint SP Tm
Sets the delay time before a “Setpoint Not Met” condition
occurs. The pump protection criteria set in P1-15 must be met
before the timer will start.
Setting P1-15 to 0.0 disables this function.
Default: 60 s
Min.: 0
Max.: 3600
226
P1-17
(0C10)
Not Maintaining
Setpoint Selection
Not Maint SP Sel
0: Fault
1: Alarm
2: Digital Output
Selects the drive response method during the “Not Maintaining
Setpoint” condition.
0: Fault
1: Alarm
2: Digital out only
Default: 0
Range: 0 to 2
226
P1-18
(0C11)
Prime Loss Detection
Method
Prime Loss Mthd
0: Current (A)
1: Power (kW)
2: Torque (%)
Determines the quantity used to determine loss of prime.
0: Current (A)
1: Power (kW)
2: Torque (%)
Default: 0
Range: 0 to 2
226
P1-19
(0C12)
Prime Loss Level Prime Loss Level
Detects loss of prime in the pump when in Auto or Sleep Boost
Mode.
When the measured quantity determined by P1-18 drops below
this level for the time set in P1-20 and the output frequency is
above the level set in P1-21, a “Loss of Prime” condition occurs.
The drive responds to the “Loss of Prime” condition depending
on the setting of P1-22, Loss of Prime Selection.
Default: 0.0 A
<4>
Min.: 0.0
Max.: 1000.0
227
P1-20
(0C13)
Loss of Prime Time Prime Loss Time
Sets the delay time before a “Loss of Prime” condition occurs.
The pump protection criteria set in P1-18 and P1-19 must be met
before the timer will start.
Default: 20 s
Min.: 0
Max.: 600
227
P1-21
(0C14)
Loss of Prime
Frequency
Prime Loss Freq
Sets the frequency level above which the “Loss of Prime”
detection is enabled when set to a value other than 0.
When set to 0 (default), the frequency level is determined by the
smaller value between (Fmax - 1 Hz) and (d2-01 - 1 Hz).
Default: 0.0 Hz
Min.: 0.0
Max.: [E1-04]
227
P1-22
(0C15)
Loss of Prime Selection
Prime Loss Sel
0: Fault
1: Alarm
2: Digital Output
Sets the drive response method during the “Loss of Prime”
condition.
0: Fault
1: Alarm
2: Digital out only
Default: 0
Range: 0 to 2
227
P1-23
(0C16)
Loss of Prime
Maximum Restart Time
after Fault
LOP Max Rstrt T
Sets the time in minutes that the drive will wait before
attempting another restart when the restart fails or is not
attempted due to a continuing fault condition.
Default: 0.2 min
Min.: 0.2
Max.: 6000.0
227
P1-30
(0C1D)
Low Water Digital Input
Configuration
Low Water DI Sel
0: Normally Open
1: Normally Closed
Selects the configuration of the low water level digital input.
0: Normally open
1: Normally closed
Default: 0
Range: 0, 1
228
B.12 P: Pump Parameters
