YASKAWA iQpump Micro CIMR-PW Series

Table 2.8 Dimensions for IP66/NEMA 4X, UL Type 4X Enclosure Drives
4-M6
F
C
B
A
E
3-
22
3- 50
W
W1
H
H1
H2
D
t1
Voltage
Class
Drive Model
Dimensions mm (in)
W H D W1 H1 H2 t1 A B C E F
Wt.
kg (lb.)
Three-
Phase
200 V Class
2V0069G
290
(11.42)
465
(18.31)
305
(12.01)
265
(10.43)
445
(17.52)
8.5
(0.33)
2.5
(0.10)
173
(6.81)
188
(7.40)
248
(9.76)
130
(5.12)
160
(6.30)
27.7
(61.07)
2.2 Mechanical Installation
36
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
