Table B.4 Three-Phase, 200 V Class Drives Default Settings by Drive Capacity
No. Description Unit Default Settings
− Model − 2V0006 2V0010 2V0012 2V0020 2V0030
o2-04 Drive Model Selection Hex 63 65 66 68 6A
E2-11 Motor Rated Power kW 1.1 2.2 3.0 5.5 7.5
b3-06 Speed Search current 1 − 0.5 0.5 0.5 0.5 0.5
b3-08
Current Control Gain during Speed Search (Speed
Estimation Type)
– 0.5 0.5 0.5 0.5 0.5
C6-02 Carrier frequency − 7 7 7 7 7
E2-01 Motor rated current A 4.9 8.5 11.4 19.6 26.6
E2-02 Motor rated slip Hz 2.6 2.9 2.7 1.5 1.3
E2-03 Motor no-load current A 2.3 3.0 3.7 5.1 8.0
E2-05 Motor line-to-line resistance Ω 3.577 1.601 1.034 0.399 0.288
E2-06 Motor leakage inductance % 18.5 18.4 19 18.2 15.5
E2-10 Motor Iron Loss W 38 77 91 172 262
L2-02 Momentary power loss ride-through time s 0.2 0.3 0.5 1 1.0
L2-03 Momentary power loss Baseblock time s 0.4 0.5 0.5 0.7 0.8
L2-04 Momentary power loss voltage recovery time s 0.3 0.3 0.3 0.6 0.6
L2-05 Uv detection voltage V dc 190 190 190 190 190
L3-24 Motor acceleration time s 0.142 0.145 0.145 0.168 0.175
L8-02 Overheat alarm level °C 100 100 100 110 115
L8-09 Ground fault selection − 0 0 0 0 1
L8-38 Carrier frequency reduction selection − 1 1 1 1 2
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10
B.17 Defaults by Drive Model
378
