Table B.5 Three-Phase 400 V Class Drives Default Settings by Drive Capacity
No. Description Unit Default Settings
− Model − 4V0002 4V0004 4V0005 4V0007 4V0009
o2-04 Drive Model Selection Hex 92 93 94 95 96
E2-11 Motor rated power kW 0.75 1.5 2.2 3.0 3.7
b3-06 Speed Search current 1 − 0.5 0.5 0.5 0.5 0.5
b3-08
Current Control Gain during Speed Search
(Speed Estimation Type)
– 0.5 0.5 0.5 0.5 0.5
C6-02 Carrier frequency − 7 7 7 7 7
E2-01 Motor rated current A 1.6 3.1 4.2 5.7 7
E2-02 Motor rated slip Hz 2.6 2.5 3 2.7 2.7
E2-03 Motor no-load current A 0.8 1.4 1.5 1.9 2.3
E2-05 Motor line-to-line resistance Ω 22.459 10.1 6.495 4.360 3.333
E2-06 Motor leakage inductance % 14.3 18.3 18.7 19 19.3
E2-10 Motor Iron Loss W 26 53 77 105 130
L2-02 Momentary power loss ride-through time s 0.1 0.2 0.3 0.5 0.5
L2-03 Momentary power loss Baseblock time s 0.3 0.4 0.5 0.5 0.6
L2-04 Momentary power loss voltage recovery time s 0.3 0.3 0.3 0.3 0.3
L2-05 Uv detection voltage V dc 380 380 380 380 380
L3-24 Motor acceleration time s 0.142 0.166 0.145 0.145 0.154
L8-02 Overheat alarm level °C 110 110 90 100 100
L8-09 Ground fault selection − 0 0 0 0 0
L8-38 Carrier frequency reduction selection − 1 1 1 1 1
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10
B.17 Defaults by Drive Model
