YASKAWA iQpump Micro CIMR-PW Series

n
Single-Phase 200 V Class
Table D.12 Wire Gauge and Torque Specifications
Drive
Model
Terminal
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening
Torque
N•m (lb.in.)
BV0006
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
BV0010
R/L1, S/L2, T/L3 10 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
BV0012
R/L1, S/L2, T/L3 10 14 to 10
M4
2.3 to 2.5
(20.4 to 22.1)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
BV0018
R/L1, S/L2, T/L3 8 12 to 8
M5
2.3 to 2.5
(20.4 to 22.1)
U/T1, V/T2, W/T3 10 12 to 8
, 1, 2
– 12 to 8
B1, B2 – 12 to 8
8 12 to 8
2 to 2.5
(17.7 to 22.1)
n
Three-Phase 200 V Class
Table D.13 Wire Gauge and Torque Specifications
Drive
Model
Terminal
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening
Torque
N•m (lb.in.)
2V0006
R/L1, S/L2, T/L3 14 18 to 14
M3.5
0.8 to 1.0
(7.1 to 8.9)
U/T1, V/T2, W/T3 14 18 to 14
, 1, 2
– 18 to 14
B1, B2 – 18 to 14
14 18 to 14
2V0010
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
2V0012
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
2V0020
R/L1, S/L2, T/L3 10 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 10 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
D.1 UL Standards
436
