YASKAWA iQpump Micro CIMR-PW Series

Drive
Model
Terminal
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening
Torque
N•m (lb.in.)
2V0056
R/L1, S/L2, T/L3 4 6 to 4
M6
5.4 to 6.0
(47.8 to 53.1)
U/T1, V/T2, W/T3 4 6 to 4
, 1, 2
– 6 to 4
B1, B2 – 10 to 6 M5
2.7 to 3.0
(23.9 to 26.6)
6 8 to 4 M6
5.4 to 6.0
(47.8 to 53.1)
2V0069
R/L1, S/L2, T/L3 3 8 to 2
M8
9.9 to 11
(87.6 to 97.4)
U/T1, V/T2, W/T3 3 8 to 2
, 1, 2
– 8 to 2
B1, B2 – 8 to 6 M5
2.7 to 3.0
(23.9 to 26.6)
6 6 to 4 M6
5.4 to 6.0
(47.8 to 53.1)
n
Three-Phase 400 V Class
Table 3.6 Wire Gauge and Torque Specifications
Drive
Model
Terminal
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening
Torque
N•m (lb.in.)
4V0002
4V0004
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
14 14 to 10
4V0005
4V0007
4V0009
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
4V0011
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
4V0018
R/L1, S/L2, T/L3 10 14 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 10 14 to 6
, 1, 2
– 14 to 6
B1, B2 – 14 to 10
8 14 to 6 M5
2 to 2.5
(17.7 to 22.1)
4V0023
R/L1, S/L2, T/L3 10 10 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 10 10 to 6
, 1, 2
– 10 to 6
B1, B2 – 14 to 10
8 10 to 6 M5
2 to 2.5
(17.7 to 22.1)
3.6 Main Circuit Wiring
