Figure 3.17 Multiple Drive Wiring
n
Wiring the Main Circuit Terminal
WARNING! Electrical Shock Hazard. Shut off the power supply to the drive before wiring the main circuit terminals. Failure to comply may
result in death or serious injury.
Note: A cover placed over the DC Bus and braking circuit terminals prior to shipment helps prevent miswiring. Cut away covers as needed for
terminals with a needle-nose pliers.
A
A –Protective Cover to Prevent Miswiring
Note: The ground terminal screw on IP20/NEMA 1, UL Type 1 holds the protective cover in place on model 2V0006.
3.6 Main Circuit Wiring
54
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
