(P2-02) lower than the PID setpoint and set the Draw Down Level (P1-04) slightly above the PID setpoint to prevent
the drive from waking up until the water exceeds the desired depth setting. Sleeping helps the drive save energy and
mechanical wear. When P1-04 is set to 0 (default), the sleep function is disabled.
Related Parameters
No. Parameter Name Setting Values
A1-01 Access Level Selection
Default: 2
Range: 0 to 3
A1-03 Initialize Parameters
Default: 0
Range: 0 to 5550; 6008, 6009, 7770, 7771
E2-01 Motor Rated Current
Default: Depends on o2-04
Min.: 10% of drive rated current
Max.: 200% of drive rated current
E2-04 Number of Motor Poles
Default: 2
Min.: 2
Max.: 48
P1-03 Feedback Device Scaling
Default: 145.0 PSI
Min.: 0.1
Max.: 6000.0
P1-11 High Feedback Level
Default: 155.0 PSI
Min.: 0.0
Max.: 6000.0
P1-06 Minimum Pump Speed
Default: 40.0 Hz
Min.: 0.0
Max.: [E1-04]
P1-04 Start / Draw Down Level
Default: 0.0 PSI
Min.: -999.9
Max.: 999.9
P2-02 Sleep Level
Default: 0.0 Hz
Min.: 0.0
Max.: 6000.0
P4-10 AUTO Mode Operator Run Power Down Storage
Default: 0
Range: 0, 1
P5-02 HAND Speed Reference 1
Default: 40.0 Hz
Min.: 0
Max.: [E1-04]
P5-04 HAND Key Function Selection
Default: 1
Range: 0, 1
Q1-01 PID Controller Setpoint 1
Default: 0.0
Min.: 0.0
Max.: 6000.0
U1-99 Anti-No-Flow Timer No signal output available
4.8 iQpump Presets and Functions
88
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
