11-9
170904-1CD
HW1482870
11 Parts List
11.4B-,T-Axes Unit
MPL80
II
4055 M4X6 Socket screw 1
4056 2H-4 Spring washer 1
3017 HW0102239-2 Casing 1
Table 11-4: B-,T-Axes Unit
No. DWG No. Name
Pcs.
