Appendix B
B.1 Illustrated Parts List
RM2-755/1255SL
Positioner
Table B-7: Arm Assembly, Swing, Headstock Main Drive with Lube, RM2-755SL
ITEM PART
NUMBER
DESCRIPTION QTY
184300-1 ARM ASSY,SWING,HEADSTOCK MAIN DRIVE W/LUBE,RM2-
755SL
1 180286-1 HOUSING,HEADSTOCK SWINGARM,RM2-755,RDR 1
2 140786-5 BEARING.SLEWING,EXTERNAL GEAR,M3XHD/MR300,
CONTOUR HARDENED
1
3 130532-24 SCREW, SHC, M16x2 X 55, CLASS12.9 23
4 132049-1 WASHER, CONICAL SPRING, GTS16 23
5 163888-2 DRIVE ASSY,MAIN SWEEP AXIS,RM2-755SL,HARDEN PINION 1
6 166341-1 WIPER, RUBBER, HEADSTOCK SWINGARM, RM2-755SL 1
7 130425-3 SCREW,BHSC,M6 X 12 4
8 130533-19 SCREW, SHC, M20x2.5 X 220, CLASS 12.9 2
9 147177-1 WASHER, CONICAL SPRING, M20 8
10 184298-2 TUBING,LUBRICATION LINE,LH,.25 OD,SSTL,MAIN DRIVE W/
LUBE,RM2-755SL
1
11 184799-1 FITTING,STRAIGHT MALE CONNECTOR,FLARELESS,1/8-27
NPTF,0.25 TUBE,STEEL
2
12 184217-1 BLOCK,MANIFOLD,3-PORT .125 BSPT,MAIN DRIVE W/
LUBE,RM2-755SL
1
13 472303-9 SCREW,SHC,M12X50,CLASS 12.9, 1
14 471075-1 WASHER,CONICAL SPRING,GTS12,YS 1
15 184298-1 TUBING,LUBRICATION LINE,RH,.25 OD,SSTL,MAIN DRIVE W/
LUBE,RM2-755SL
1
16 132652-9 PIN, DOWEL,M20X40 2
17 130533-18 SCREW, SHC, M20x2.5 X 100, CLASS 12.9 6
18 166337-1 COVER, GEAR, HEADSTOCK SWINGARM 1
19 148102-4 SCREW_SHC_M6X16_JIS 0209_W/CAPTIVE LOCK &
FLAT_BLACK
2
20 167751-1 BRACKET, LUBE BLOCK, MIAN DRIVE GEARS 1
21 137147-3 SCREW,PPH,M5X10,JIS B 1188,W/CAPTIVE LOCK & FLAT
WASHERS
2
22 130431-1 CLAMP, WIRE, PLASTIC, P-STYLE, 1/8' 2
23 130425-3 SCREW,BHSC,M6X12 3
24 470602-1 WASHER,CONICAL SPRING,GTS6,YS 3
27 182163-1 TUBE,CONN ASSY,1/8 BSPTM X 1/4 TUBE 1
