YASKAWA RM2-755/1255SL User Manual

4-1
166006-1CD
166006-1CD
4 Basic Specifications
4.1 Basic Specifications List
RM2-755/1255SL
Positioner
4 Basic Specifications
4.1 Basic Specifications List
Table 4-1: RM2-755/1255SL Positioner Technical Specifications
CAUTION
• Do not operate outside the standard setup, without Yaskawa
approval.
Working outside the standard setup may change E-Stop performance
and void the warranty.
SPECIFICATION UNITS RM2-755SL RM2-1255SL
Model P/N Prior to
August
2018
172986-1 (2.0M)
173480-1 (3.0M)
173481-1 (2.0M)
173482-1 (3.0M)
After
August
2018
184301-1 (2.0M)
184302-1 (3.0M)
184616-1 (2.0M)
184617-1 (3.0M)
Rated Payload kg/lb 755/1665 1255/2767
Load Height
(floor to centerline)
mm 894 894
Sweep Motor Power
(Before Nov. 2017)
kW 2 3.7
Sweep Motor Power
(Nov. 2017 or later)
3.7 3.0
Tooling Motor Power kW 1.3 3.7
Rated Sweep Time sec 2.25 3.25
Rated Sweep Speed rpm 25.3 11.0
Rated Sweep Torque
(Before Aug. 2018)
N·m/lb·ft 3345/2467 6556/4835
Rated Sweep Torque
(Aug. 2018 or Later
5161 / 3806
Tooling Torque N·m 957/705 3260/2405
Tooling Axis Ratio 153:1 185:1
Sweep Axis Ratio 53:10062 27:10062
Max. Tooling
Envelope
mm 1300 1300
Max. Tooling Sweep mm 2675 2675
Static Load (side A/B) kg 250 300
Dynamic Load
(side A/B)
kg 200
200
47 of 145
