2 Installation
2.3 Positioner Installation
RM2-755/1255SL
Positioner
2.3.4 Mounting Positioner
Mount the Positioner firmly on a baseplate or foundation strong enough to
support the Positioner and withstand repulsion forces in acceleration and
deceleration.
Construct a solid foundation with the appropriate thickness to withstand
maximum repulsion forces of the Positioner.
CAUTION
• The floor should be strong enough to support the Positioner.
Construct a solid foundation with the appropriate thickness to
withstand maximum repulsion forces of the Positioner. Make sure
the thickness of the floor is 200mm or more because any
thickness less than 200mm is insufficient for mounting, even if the
floor is concrete. Before mounting the Positioner on the floor,
check the flatness, cracks, etc. of the floor and repair before
installing.
Shape of the Positioner may deform and its functional ability may be
compromised.
• Make sure the floor flatness and level complies with ASTM E1155
code minimum values of Ff of 20 and FI of 15.
If the flatness of the mounting face is insufficient, the shape of the
Positioner may deform and its functional ability may be compromised.
• Consult with a licensed civil engineer if the strength or integrity of
the floor is in question.
Not consulting a licensed civil engineer if there is any question
concerning the strength or integrity of the floor can cause equipment
damage.
