4-3
166006-1CD
166006-1CD
4 Basic Specifications
4.2 Part Names and Working Axes
RM2-755/1255SL
Positioner
4.2 Part Names and Working Axes
Fig. 4-1: Part Names and Working Axes
4.3 Mounting Dimensions
Fig. 4-2: Mounting Dimensions (swingarms removed for clarity)
FORKLIFT
POCKETS
HEADSTOCK
ARC SCREEN ASSY
TAILSTOCK
SWINGARM
ASSEMBLY
TOOLING PLATE
MOTOMOUNT
“B”
2.0M 2993mm
3.0M 3993mm
“B” DIMENSIONS
25
1240
1190
25
50
250
450
500
550
330
280
230
140
50
25
8X M20 X 2.5 THRU
12X Ø 20.0 THRU
+0.7
-0.0
