6-10

166006-1CD

6 Maintenance and Inspection

6.3 Grease Replenishment/Exchange for Speed Reducers

RM2-755/1255SL

Positioner

6.3.2 Tooling Axes Reducer

1. Remove the button head screws in the vent located in the flat surface

at the top of the drive assembly.

Fig. 6-10: Tooling Greasing

2. Install the M6 grease fitting in the faceplate and pump Moly-White

RE00 grease through the reducer.

3. Reinstall the M6 button head screw and remove the M6 grease fitting.

Button Head Screw

Grease Fitting

61 of 145
