2 Installation
2.4 Customer-Supplied Tooling Fixtures
RM2-755/1255SL
Positioner
2.4 Customer-Supplied Tooling Fixtures
The Positioner is equipped with a MotoMount tool mounting system (see
Fig. 1-1 “Positioner Assembly” on page 1-2). MotoMount is a flexible tool
mounting system for headstock / tailstock style Positioners, such as the
Positioner. MotoMount provides improved part presentation repeatability
compared to traditional hard-mounted systems.
The MotoMount system also minimizes headstock / tailstock bearing loads
induced by tooling and headstock / tailstock misalignment (up to a
maximum of ±2 degrees), transmitting only the predictable moment loads
resulting from simple beam loading.
For additional information on the correct use and care of the MotoMount
tool mounting system, please contact Customer Support. (Refer to section
1.7 “Customer Support Information” on page 1-6).
NOTICE
The customer shall supply all tooling fixtures for the Positioner.
Yaskawa recommends application of a corrosion/rust preventive
compound to tooling fixtures located in a high-humidity environment.
