B-25
166006-1CD
166006-1CD
Appendix B
B.1 Illustrated Parts List
RM2-755/1255SL
Positioner
Table B-8: Major Assemblies — RM2-1255SL, 2.0M with MultiPort Lubricator
ITEM NO. PART NUMBER DESCRIPTION QTY
184616-1
POSITIONER ASSY,RM2-1255,W/LUBE,W/O SWITCHES,SLIP-
RINGS,AND AIR
1 173479-3 HOUSING ASSY,HEADSTOCK, PINION LUBE OPT,RM2-1255SL 1
2 163893-1 DRIVE ASSY, MH1655 HEADSTOCK, W/MOTOMOUNT 2
3 164218-3 BEAM,Z-SPREADER, PIN TO PIN 1
4 163900-1 ARM ASSY, SWING, TAILSTOCK 1
5 163887-1 HOUSING, COLUMN, TAILSTOCK 1
6 184620-1 ARM ASSY, SWING, HEADSTOCK MAIN DRIVE,RM2-1255 1
7 148102-4 SCREW_SHC_M6X16_JIS 0209_W/CAPTIVE LOCK &
FLAT_BLACK
17
8 175284-1 COVER,Z-BEAM,END,LH,W/STUDS,RM2-755/1255SL 1
9 166426-2 SHIELD, ARC, Z-BEAM, RM2-755/1255SL 2
10 148102-5 SCREW, SHC, M6X20, W/CAPTIVE FLAT & LOCK WASHER 10
11 175287-1 COVER,Z-BEAM,END,RH,W/STUDS,RM2-755/1255SL 1
12 166721-1 COVER, CABLES, TAILSTOCK SWINGARM, RM2-755/1255SL 2
13 152364-2 SCREW, HHC, M5 X 12 12
14 131275-4 SCREW,HHC,M20X55,ZP,CLASS 8.8 8
15 184290-1 COVER,Z-BEAM,END,LH,MAIN DRIVE,W/STUDS,RM2-1255SL,
W/PINION LUBE
1
16 164532-2 LABEL, PRODUCT, IDENTIFICATION, THREE AXIS
POSITIONER
1
17 166410-1 COVER, HEADSTOCK SWINGARM 1
18 131274-3 SCREW, HHC, M16X35, ZP, CLASS 8.8 4
19 479147-9 WASHER,FLAT, M16,ZP 6
20 131274-4 SCREW,HHC,M16X40,ZP,CLASS 8.8 28
21 132049-1 WASHER, CONICAL SPRING, GTS16 44
22 166355-1 PIN,DOWEL,PULL,M20 x 40,HARDENED STEEL,NF
DIN7979D,M6 INTERNAL THRD
4
23 130532-15 SCREW, SHC, M16X60, CLASS12.9 16
24 163783-1 PIN, DOWEL, M16 X 40, m6, ALLOY STL 4
25 472303-11 SCREW,SHC,M12X60,CLASS 12.9 22
26 471075-1 WASHER, CONICAL SPRING, GTS12, YS 22
27 164522-1 SPACER, GEAR BEARING, MAIN DRIVE 1
28 182262-1 COVER,MAIN DRIVE,PINION LUBE,RM2-1255SL 1
29 130887-9 NEGATIVE WELD CABLE, 1.4M 5
30 137146-4 SCREW, PPH, M4 X 12, JIS B1188,W/CAPTIVE LOCK & FLAT
WASHER
12
31 158277-1 CABLE ASSY,P/T,ENCODER,DX100,3 EXT AXIS,MALE,SLIM
LINE
1
32 137146-3 SCREW, PPH, M4 X 10, JIS B 1188,W/CAPTIVE LOCK & FLAT
WASHER
16
