YASKAWA RM2-755/1255SL User Manual

B-27
166006-1CD
166006-1CD
Appendix B
B.1 Illustrated Parts List
RM2-755/1255SL
Positioner
71 470617-1 WASHER,CONICAL SPRING, GTS8 2
72 182172-1 FITTING,1/4 IN MALE,HEX NIPPLE 1
73 182165-1 ADAPTER,STRAIGHT TUBING, 1/4 IN 1
74 182171-1 FITTING,CROSS TUBE,1/4 IN NFPT FEMALE 1
75 184367-1 GROMMET,RUBBER,STYLE 1,1.25 ID,1.75 OD,.25 PANEL THK,
FOR 1.5 DIA HOLE
1
76 184615-1 GAGE, PRESS, 0-600 PSI, 1/8 NPT 1
77 179885-1 TUBING,NYLON,14 OD, SEMIRIGID HIGH STRENGTH, 0.050
WALL,625 PSI (WORKING), BLACK
1
78 184614-1 PUMP,MULTIPORT,24 VDC, NO LEVEL SENSOR 1
79 145787-2 FITTING,ELBOW,M/F,90DEGREE, 1/4BSPT 1
80 185247-1 PLATE,GLAND,RM2 POSITIONERS, 1 X 1.375-18 1
81 182169-1 SWITCH,PRESSURE,75-300PSI,1/8 NPT MALE,SPDT 1
82 185251-1 CABLE ASSY,PIGTAIL,28-PIN ECO-MATE TO 24-PIN
MICROFIT,20AWG WIRES,1500MM,LUBE
1
83 185256-1 CABLE ASSY,PIGTAIL, POSITIONER LUBE KIT 1
ITEM NO. PART NUMBER DESCRIPTION QTY
107 of 145
