YASKAWA RM2-755/1255SL User Manual

B-37
166006-1CD
166006-1CD
Appendix B
B.1 Illustrated Parts List
RM2-755/1255SL
Positioner
Table B-12: Tailstock Swing Arm Assembly
ITEM NO. PART NO. DESCRIPTION Qty
163900-1 Tailstock Swing Arm Assembly
1 163840-1 HOUSING,TAILSTOCK SWINGARM 1
2 164890-1 HOUSING ASSY, TAILSTOCK ADAPTER, MOTOMOUNT 2
4 165038-1 SHAFT, BEARING, TAILSTOCK SWINGARM 1
5 163886-1 BEARING,SPHERICAL,PILLOW BLOCK,2.437 ID 1
6 157188-1 RETAINER, TAILSTOCK SWINGARM 1
7 132619-3 SCREW, FHSC, M8x1.25 X 20 1
8 130532-2 SCREW, SHC, M16 X 35,CLASS12.9 8
9 132049-1 WASHER, CONICAL SPRING, GTS16 8
10 479297-5 SCREW, SHC, M10x1.5 X 30, CLASS 12.9 12
11 470541-1 WASHER, CONICAL SPRING, GTS10 12
12 137298-2 SCREW, SHOULDER, 1/2” DIA X 2 1/2” LG X 3/8”-16 THD 2
13 152712-1 WASHER, BELLEVILLE, .505" ID X 1" OD 30
14 130441-7 NUT, HEX, 3/8 2
