2 Installation
2.3 Positioner Installation
2-6
166006-1CD
166006-1CD
RM2-755/1255SL
Positioner
Fig. 2-1: Mounting the Positioner to the Floor
280.0
(B)
283
(550)
500.0
450.0
250.0
50.0
25.0
25.0
(1240)
1190.0
8X M20 2.5 THRU
12X Ø20.0 THRU
+0.7
-0.0
25.0
50.0
140.0
230.0
(330)
PLAN VIEW POSITIONER
MOUNTING DIMENSIONS
SWINGARMS REMOVED
FOR CLARITY
2.0M 2993mm
3.0M 3993mm
“B” DIMENSIONS
ONLY INCLUDED
WITH MULTIPORT
LUBRICATOR
