2-20

166006-1CD

2 Installation

2.6 Adjusting the Hardstops

RM2-755/1255SL

Positioner

3. If there is a gap, loosen the adjustable bolt hardstop so it just touching

the plunger bolt. If it is compressing the plunger bolt, rotate the

adjustable bolt hardstop so it is only touching the plunger bolt and

tighten the lock nut on the adjustable bolt hardstop to 250Nm.

4. Rotate the swingarm to the “B” side and repeat section 2.6 “Adjusting

the Hardstops”.

NOTICE

After adjusting the hardstops, the home positions can be set. Refer to

section 6.12 “Positioner Home Position” on page 6-21 to set the home

positions
