YASKAWA RM2-755/1255SL User Manual

B-5
166006-1CD
166006-1CD
Appendix B
B.1 Illustrated Parts List
RM2-755/1255SL
Positioner
31 158277-1 CABLE ASSY,P/
TENCODER,DX100,3 EXT
AXIS,MALE,SLIM LINE
1
32 176281-1 COVER,GLAND PLATE,RM2
POSITIONERS,I/O CABLE
ASSY.DX200
1
33 137146-3 SCREW, PPH, M4 X 10, JIS B
1188,W/CAPTIVE LOCK & FLAT
WASHER
16
34 169712-2 CABLE ASSY,PIGTAIL,SLIPRING,
MALE, BKHD,AUX PWR & I/O
,DX200, DUAL, 8M
1
35 164842-1 164843-1 CABLE ASSY,PIGTAIL,POWER,3
AXIS,SIGMA V
1
36 137147-4 SCREW,PPH,M5X12,JIS B 1188,W/
CAPTIVE LOCK & FLAT
WASHERS
4
37 131274-8 SCREW, HHC, M16 X 60, ZP,
CLASS 8.8
2
38 166408-2 COVER, TAILSTOCK HOUSING,
ROUND HOLE
2
50 155235-2 LABEL, PATENT IDENTIFICATION 1
52 143047-7 PLATE,GLAND,XRC/MRC,BLANK 4
53 157171-1 PLATE, GLAND, POSITIONER 1
54 170543-1 BRACKET, SHIPPING, FORMED,
RM2-755/1255SL
1
55 170544-1 BRACKET, SHIPPING, ANGLE,
RM2-755/1255SL
1
56 131272-11 SCREW, HHC, M12 X1.75x 20,LG 1
57 479147-7 WASHER, FLAT, M12, ZP 1
58 130424-5 SCREW,BHSC,M5 X 12 6
59 175288-1 COVER,Z-
BEAM,END,RH,SHIPPING
BRKT,W/STUDS
1
68 152310-5 PLATE, GLAND, SPLIT FOAM,
XRC/NX/DX,12MM CBL, 25X48
PASS-THRU,ZINC PLATE
3
73 180047-1 PLATE,STRIKER,LEVELING
SCREW
8
74 180545-1 LABEL,GREASE,MOBIL CM-P
No.2
1
ITEM NO. RM2-755SL,
2.0M PART NO.
RM2-1255SL,
2.0M PART NO.
DESCRIPTION 755
QTY
1255
QTY
85 of 145
