YASKAWA RM2-755/1255SL User Manual

B-7
166006-1CD
166006-1CD
Appendix B
B.1 Illustrated Parts List
RM2-755/1255SL
Positioner
Table B-2: Major Assemblies — RM2-755L and 1255SL, 3.0M with Grease Fittings
ITEM NO. RM2-755SL 3.0M
PART NO.
RM2-1255SL 3.0M
PART NO.
DESCRIPTION 755
QTY
1255
QTY
173480-1 173482-1 POSITIONER ASSY
1 173479-1 173479-2 HOUSING ASSY, HEADSTOCK 1
2 163892-1 1639893-1 DRIVE ASSY, HEADSTOCK,
TOOLING, W/MOTOMOUNT &
SWITCHES
2
3 164218-1 BEAM, Z-SPREADER 1
4 163900-1 ARM ASSY, SWING, TAILSTOCK 1
5 163887-1 HOUSING, COLUMN, TAILSTOCK 1
6 163896-1 163897-1 ARM ASSY, SWING, HEADSTOCK,
MAIN DRIVE
1
7 148102-4 SCREW_SHC_M6X16 17
8 175284-1 COVER, Z-BEAM, END, LH 1
9 166426-1 SHIELD, ARC, Z-BEAM, 747mm,
RM2-755/1255SL
4
10 148102-5 SCREW, SHC, M6X20, W/
CAPTIVE FLAT & LOCK WASHER
34 29
11 175289-1 STRAP, Z-BEAM ARC SHIELD 4
12 166426-3 SHIELD, ARC, Z-BEAM, 1563mm,
RM2-755/1255SL
2
13 175287-1 COVER, Z-BEAM, END, RH 1
14 166721-1 COVER, CABLES, TAILSTOCK
SWINGARM, RM2-755/1255SL
2
15 152364-2 SCREW, HHC, M5 X 12 12
17 175285-1 175286-1 COVER, Z-BEAM, END, LH, MAIN
DRIVE
1
18 164532-1 164532-2 LABEL, PRODUCT,
IDENTIFICATION, THREE AXIS
POSITIONER
1
19 169718-1 166410-1 COVER,HEADSTOCK SWINGARM 1
20 131274-3 SCREW,HHC,M16X358 4
21 479147-9 WASHER,FLAT,M16 6
22 131274-4 SCREW,HHC,M16X40 28
23 132049-1 WASHER,CONICAL SPRING,
GTS16
44
24 166355-1 PIN,DOWEL,M20X40, 4
25 130532-15 SCREW,SHC,M16X60 16
26 163783-1 PIN, DOWEL, M16 X 40, M6,
ALLOY STL
4
27 472303-11 SCREW,SHC,M12X60 22
28 471075-1 WASHER,CONICAL SPRING,
GTS12
22
29 164522-1 SPACER,GEAR BEARING,MAIN D 1
30 166339-1 166340-1 COVER,MAIN DRIVE, 1
87 of 145
