YASKAWA RM2-755/1255SL User Manual

B-10
166006-1CD
166006-1CD
Appendix B
B.1 Illustrated Parts List
RM2-755/1255SL
Positioner
Table B-3: Main Drive Headstock Swing Arm Assembly with Grease Fittings
ITEM NO. RM2-755SL,
PART NO.
RM2-1255SL,
PART NO.
DESCRIPTION 755
Qty
1255
Qty
163896-1 163897-1 MAIN DRIVE HEADSTOCK
SWING ARM ASSEMBLY
1 163834-1 163834-2 HOUSING, HEADSTOCK
SWINGARM
1
2 140786-3 BEARING.SLEWING,EXTERNAL
GEAR,M3XHD/MR300,HARDENED
1
3 132049-1 WASHER, CONICAL SPRING,
GTS16
23
4
130532-24
SCREW, SHC, M12 X 55,CLASS
12.9
23
5 na 164817-1 BLOCK, STOP, MAIN DRIVE
SWINGARM
2
6 na 152712-1 WASHER, BELLEVILLE, .505" ID X
1" OD
32
9 na 164816-1 PIN, DOWEL, M20 X 50 m6,
HARDEN STL
4
10 471075-1 WASHER, CONICAL SPRING, M12 1 9
11 na 472303-10 SCREW, SHC, M12 X 55,CLASS
12.9
8
12 na 137298-7 SCREW, SHOULDER, 1/2” X 3" LG
X 3/8”-16 THD
2
13 na 130441-7 NUT, HEX, 3/8 2
15 132652-9 PIN, DOWEL,M20X40 2
16 165175-1 SHIM, 0.0100", MAIN DRIVE MTG 1
17 165175-2 SHIM, 0.0050", MAIN DRIVE MTG 1
18 163888-1 163889-1 DRIVE ASSY, MAIN SWEEP AXIS 1
19 147177-1 WASHER, CONICAL SPRING, M20 8
20 130533-19 SCREW, SHC, M20x2.5 X 220,
CLASS 12.9
2
21 130533-18 SCREW, SHC, M20x2.5 X 100,
CLASS 12.9
6
22 166337-1 166338-1 COVER, GEAR, HEADSTOCK
SWINGARM
1
23 130425-3 SCREW,BHSC,M6 X 12 7
24 148102-4 SCREW_SHC_M6X16_JIS
0209_W/CAPTIVE LOCK &
FLAT_BLACK
2
25 166341-1 166342-1 WIPER, RUBBER, HEADSTOCK
SWINGARM
1
26 167753-1 167754-1 LUBRICATOR ASSY, MAIN DRIVE,
RM2-1255/1555/2355
1
29 470602-1 WASHER, CONICAL, SPRING,
GTS6, YS
3
30 179842-1 MOUNT,GREASE TAB 1
90 of 145
