Step Display Example Description
1
B B - FUNCTION -
Fn01E:SvMotOp ID
Fn01F:FBOpMot ID
Fn020:S-Orig Set
Fn030:Soft Reset
Press the Key to open the
Utility Function Mode main menu,
and select Fn01F using or
Key.
3
B B - FBOpMotID -
Encoder
UTTAH-U11DB
Serial No.
11 bit - INC
Encoder Type/Resolution
Encoder Type
Press the key, and the
encoder ID will be shown.
Use the and Keys to
scroll left and right through the
information.
5
B B - FUNCTION -
Fn01E:SvMotOp ID
Fn01F:FBOpMot ID
Fn020:S-Orig Set
Fn030:Soft Reset
Press the Key.
The display returns to the Utility
Function Mode main menu.
If a feedback option module is not connected, the following message will
appear.
B B - FBOpMotID -
Not connect
Even if a feedback option module is connected, the following message will appear if the
option module contains no motor data or encoder data.
B B - FBOpMotID -
Not available
n When using SigmaWin+
Start SigmaWin+. Click Monitor in the main menu and then click Product Information.
The linear scale pitch can be checked by using the monitor mode param-
eters Un084 (Linear Scale Pitch) and Un085 (Linear Scale Pitch Index).
When Un084 = 800, and Un085 = 6
Linear scale pitch = Un084 × 10
Un085
[pm] = 800 × 10
6
[pm] = 800 [µm]
Example
(5) How to Monitor the
Encoder / Scale Data
Using the Digital Operator
Sigma-5 and Sigma-7 Series SERVOPACKs
Set-up Procedure
Feedback Option Module Set-up
| | Feedback Option Module Type 3 - Manual version C - Revision 0 | en | 71
