5.3 Examples of I/O Signal Connections
5-11
5
5.3.4 SynqNet Connectors (CN6A and CN6B)
The following table show the terminal layout for the SynqNet connector and its specifications.
(1) Connector Specification
(2) Connector Pin Arrangement
The following tables show the arrangement of the connector pin.
Name Model Manufacturer
Unit-end Commercial Ulti-mate Micro-D connector 83611-9006 Molex
Cable-end Commercial Ulti-mate Micro-D cable receptacle 83421-9014 Molex
Pin Terminal name I/O Pin Terminal name I/O
1
CONN_RD1+
Input 6
CONN_RD1-
Input
2
RD1_COMM
− 7
RD1_COMM
−
3
EARTHGND_OUT
− 8
TD1_COMM
−
4
TD1_COMM
− 9
CONN_TD1-
Output
5
CONN_TD1+
Output
Pin Terminal name I/O Pin Terminal name I/O
1
CONN_TD0+
Output 6
CONN_TD0-
Output
2
TD0_COMM
− 7
TD0_COMM
−
3
EARTHGND_IN
− 8
RD0_COMM
−
4
RD0_COMM
− 9
CONN_TD0-
Input
5
CONN_RD0+
Input
