2.5.3 Noise Filters
2-26
2.5.3 Noise Filters
* Refer to 4.4.9 Noise Filter.
Noise Filter Brake Power Supply
Use the following noise filter at the brake power input for 400 W or less servomotors with holding brakes.
MODEL: FN2070-6/07 (Manufactured by SCHAFFNER Electronic.)
Main Circuit
Power
Supply
SERVOPACK Model Recommended Noise Filter *
Capacity
(kW)
SGDS
-
Type Specifications
Single-phase
100 V
0.05 A5F
FN2070-6/07 Single-phase 250 VAC, 6 A
0.10 01F
0.20 02F
FN2070-10/07 Single-phase 250 VAC, 10 A
0.40 04F
FN2070-16/07 Single-phase 250 VAC, 16 A
Single-phase
200 V
0.05 A5A
FN2070-6/07 Single-phase 250 VAC, 6 A
0.10 01A
0.20 02A
0.40 04A
FN2070-10/07 Single-phase 250 VAC, 10 A
0.75 08A
FN2070-16/07 Single-phase 250 VAC, 16 A
Three-phase
200 V
1.0 10A
FN258L-16/07 Three-phase 480 VAC, 16 A
1.5 15A
2.0 20A
3.0 30A FN258L-30/07
Three-phase 480 VAC, 30 A
IMPORTANT
