4.4 Peripheral Devices
4-9
4
(2) Dimensional Drawings
(3) Specifications
4.4.4 Connector Terminal Block Converter Unit
(1) Model: JUSP-TA26P
The connection diagram for the connector terminal block converter unit is shown below.
(2) Dimensional Drawings of Terminal Block
3
4
1
2
Socket: DF11-4DS-2C (Hirose Electric Corporation)
Connector: DF11-2428SCF(Hirose Electric Corporation)
1000 (39.37 ) mm (in)
-0
+20
-0
+0.79
White
Red
Black
Black
Cable Color Signal Name Explanation
White
Analog Monitor 1 Torque reference: 1 V / 100% rated
torque
Red
Analog Monitor 2
Motor speed: 1 V / 1000 min
-1
Black (2 cables)
GND (0 V) Analog monitor
GND: 0 V
SERVOPACK
Connector terminal block
converter unit model: JUSP-TA26P
CN1
B1
1
2
39
40
A1
B20
A20
Terminal block (40P)
M3.5 screw
Connector plug (40P)
FCN-364P040-AU
Can be fixed on DIN rail
Units: mm (in)
29.5 (1.16)
2- 3.5 (0.14)
3.5 (0.14)
202.5 (7.97)
B1
1
2
39
40
A1
B20
A20
3.5 (0.14)
43 (1.69)
2 (0.08)
20.5 (0.81)
15.5 (0.61)
45 (1.77)
7 (0.28)
7 (0.28)
