6 SynqNet™ Communications
6.3.1 Switch ID Setting
6-8
6.3 Settings
6.3.1 Switch ID Setting
SynqNet does not require any hardware setting for node address because node addresses are assigned by the con-
troller to each node. However, a switch ID setting may be required for higher level applications. To set the switch
ID for applications, use the rotary switches (SW1 and SW2) on the SERVOPACK’s front panel. After making the
settings, the application should re-read the switch ID.
Each rotary switch has 16 positions from hexadecimal 0 through F, so there are 256 possible settings. The switch
ID value is stored in a 32-bit address within the FPGA of the node; the upper 16 bits or the first 2 digits of the 4-
digit hexadecimal value are the rotary switch settings of SW1 and SW2, respectively.
6.3.2 SynqNet Port LED Indicators
Each SynqNet port has two LEDs. The LEDs specifically relate to the FPGA and network states. They function
independently from the drive processors or other devices attached to the node. The normal state of the LEDs dur-
ing normal operation is to be continuously lit.
Table 6.1 Example Switch ID Settings
Rotary Switch Switch ID Rotary Switch Switch ID
SW1 SW2 SW1 SW2
0 0 0x00## 1 2 0x12##
0 1 0x01## 9 A 0x9A##
0 A 0x0A## F F 0xFF##
Table 6.2 Out Port LED Indicators
LED Meaning Description
LNK
(LED 3)
Link Activity ON Link Active (Normal Operation)
OFF Link Inactive
RPTR
(LED 4)
Repeater State ON SYNQ operation [Repeater ON]
OFF Unpowered, Reset, Undiscovered, Inactive State, Repeater OFF
Blink 0.75 Hz Discovered State [Repeater ON]
Blink 1.5 Hz SYNQ Lost [Repeater ON]
Table 6.3 In Port LED Indicators
LED Meaning Description
LNK
(LED 1)
Link Activity ON Link Active (Normal Operation)
OFF Link Inactive
RCV
(LED 2)
Receive State ON SYNQ operation
OFF Unpowered, Reset, Inactive State
Blink 0.37 Hz Undiscovered State
Blink 0.75 Hz Discovered State
Blink 1.5 Hz SYNQ Lost
