9 Inspection, Maintenance, and Troubleshooting
9.1.3 Troubleshooting of Alarm and Warning
9-12
A.860
Encoder Over-
heated
(Only when an
absolute encoder
is connected)
(Detected on the
encoder side.)
Occurred when the
control power sup-
ply was turned
ON.
An Encoder fault
occurred. Replace the servomotor.
A SERVOPACK board fault
occurred. Replace the SERVOPACK.
Occurred during
operation.
The ambient temperature at servomotor is too
high.
The ambient temperature must be 40°C or less.
The servomotor load is more than the rated load. The servomotor load must be within the speci-
fied range.
An Encoder fault
occurred. Replace the servomotor.
A SERVOPACK board fault
occurred. Replace the SERVOPACK.
A.b31
Current Detec-
tion Error 1
Occurred when the
control power sup-
ply was turned ON
or during opera-
tion.
Phase-U current detection circuit fault Replace the SERVOPACK.
A.b32
Current Detec-
tion Error 2
Phase-V current detection circuit fault
A.b33
Current Detec-
tion Error 3
Power supply detection circuit fault Replace the SERVOPACK.
Servomotor cable disconnection Check the motor wiring.
A.bF0
System Alarm
0
(Internal pro-
gram processing
error)
Occurred when the
control power sup-
ply was turned
ON.
A SERVOPACK board fault
occurred. Replace the SERVOPACK.
A.bF1
System Alarm
1
(Internal pro-
gram error)
A.bF2
System Alarm
2
(Current control
processing pro-
gram error)
A.bF3
System alarm 3
(Encoder inter-
face processing
error)
A.bF4
System Alarm
4
(CPU watchdog
timer error)
A.C10
Servo Overrun
Detected
(Detected when
the servo is ON.)
Occurred when the
control power sup-
ply was turned
ON.
A SERVOPACK board fault
occurred. Replace the SERVOPACK.
Occurred when the
servo was ON or a
reference was
input.
Incorrect order of phase-U, -V, and -W in the ser-
vomotor wiring.
Correct the servomotor wiring.
An Encoder fault
occurred. Replace the servomotor.
A SERVOPACK fault
occurred. Replace the SERVOPACK.
A.C80
Absolute
Encoder Clear
Error and Multi-
turn Limit Set-
ting Error
Occurred when the
control power sup-
ply was turned ON
An Encoder fault
occurred. Replace the servomotor.
A SERVOPACK board fault
occurred. Replace the SERVOPACK.
Occurred when an
encoder alarm was
reset
An Encoder fault
occurred. Replace the servomotor.
A SERVOPACK board fault
occurred. Replace the SERVOPACK.
Table 9.3 Alarm Display and Troubleshooting (Cont’d)
Alarm
Display
Alarm Name
Situation at Alarm
Occurrence
Cause Corrective Actions
