4 Specifications and Dimensional Drawings of Cables and Peripheral Devices
4.4.9 Noise Filter
4-16
External
Dimensions
Symbol Dimensions in mm (in.)
A
113.5 ± 1
(4.47±0.039)
156 ± 1
(6.14±0.039)
119 ± 0.5
(4.69±0.020)
B
57.5 ± 1
(2.26±0.039)
85.5 ± 1
(3.37±0.039)
C
45.4 ± 1.2
(1.79±0.047)
57.6 ± 1
(2.27±0.039)
D
94 ± 1
(3.70±0.039)
130.5 ± 1
(5.14±0.039)
98.5 ± 1
(3.88±0.039)
F
103 ± 0.3
(4.06±0.012)
143 ± 0.3
(5.63±0.012)
109 ± 0.3
(4.29±0.012)
J
25 ± 0.2
(0.98±0.0079)
40 ± 0.2
(1.57±0.0079)
K
8.4 ± 0.5
(0.33±0.020)
8.6 ± 0.5
(0.33±0.020)
L
32.4 ± 0.5
(1.28±0.020)
-
M
4.4 ± 0.1
(0.17±0.004)
5.3 ± 0.1
(0.21±0.004)
4.4 ± 0.1
(0.17±0.004)
N
6 ± 0.1
(0.24±0.004)
7.4 ± 0.1
(0.29±0.004)
P
0.9 ± 0.1
(0.035±0.004)
1.2 ± 0.1
(0.047±0.004)
Q
-
66 ± 0.3
(2.60±0.012)
R
-
51 ± 0.2
(2.01±0.0079)
S
38 ± 0.5
(1.50±0.020)
-
Specifications
250 VAC,
6 A
250 VAC,
10 A
250 VAC, 16 A
Applicable
SERVO-
PACK
SGDS-
Single-
phase
100V
A5F
02F 04F
01F
Single-
phase
200V
A5A
01A
02A
04A 08A
Manufacturer
SCHAFFNER
