Yealink SIP-T40G User Manual

Customizing Your Phone
91
available when the EXP40 is connected to SIP-T48S/T48G/T46S/T46G IP phone. For more
information on how to configure the Ext Keys, refer to Assigning the Features for Ext Keys.
Details are introduced in the following:
Phone Model
Line Keys
Programmable Keys
SIP-T48S/T48G
29
13
SIP-T46S/T46G
27
13
SIP-T42S/T42G/T41S/T41P
15
11
SIP-T40G/T40P
3
11
Line Keys
You can assign predefined functionalities to line keys as well as define a label for a line key. Line
keys allow you to quickly access features, such as recall and voice call, and monitor a specific line
when the line keys are assigned with particular features, such as BLF. The default line key type is
Line or N/A (meaning that this line key provides no functionality until being configured). The
line keys on SIP-T46S/T46G/T42S/T42G/T41S/T41P IP phone can be indicated on three pages.
Details are introduced in the following:
Phone Module
Key Type
Pages Display
Line
N/A
First
Second
Third
SIP-T48S/T48G
1-16
17-29
/
/
/
SIP-T46S/T46G
1-16
17-27
1-9
10-18
19-27
SIP-T42S/T42G
1-12
13-15
1-5
6-10
11-15
SIP-T41S/T41P
1-6
7-15
1-5
6-10
11-15
SIP-T40G/T40P
3
/
/
/
/
The following figure shows an example on the SIP-T46S IP phone when assigning functionality
to line keys located in line key 1-10, the labels of line keys are indicated on the first page.
The following figure shows an example on the SIP-T46S IP phone when assigning functionality
Downloaded from ManualsNet.com search engine

Yealink SIP-T40G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Wall mountable	Yes
Wi-Fi	No
Security algorithms	AES, HTTPS, SSL/TLS
Networking standards	IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP, TFTP, HTTP, HTTPS
Voice codecs	G.711, G.711a, G.711u, G.722, G.726, G.729ab
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.6 W
Certification	CE, FCC, ISO 9001
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Volume control	Digital
Display diagonal	2.3 \
Display resolution	132 x 64 pixels
Lines quantity	3 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	175 mm
Width	212 mm
Height	54 mm
