Yealink SIP-T40G User Manual

Overview
29
If you want to
Then you can
0.
- If it is in the numeric (123) or alphanumeric
(2aB) input mode, it will provide the special
character + by long pressing about 2 seconds
on the dialing/pre-dialing screen.
For key:
- It only provides the pound character #.
For key:
- If it is in the uppercase (ABC), lowercase (abc),
uppercase and lowercase (Abc) or
alphanumeric (2aB) input mode, it will provide
the following special characters:
*.,'?!\-()@/:_;+&%=<>￡$¥¤[]{}~^¡¿§#"|.
- If it is in the numeric (123) input mode, it will
provide the following special
characters: .*:/@[].
Delete text you
entered.
Press or to position the cursor to the right
of the text you want to delete, and then press the
Delete soft key or tap to delete one character
at a time.
Delete an entire field
of data.
Swipe your finger to the left or right to select the
entire field of data, so that the data is highlighted,
and then tap the Delete soft key or . It is only
available on the SIP-T48S/T48G IP phone.
Web User Interface
In addition to the phone user interface, you can also customize your phone via web user
interface. In order to access the web user interface, you need to know the IP address of your
new phone by pressing the OK key on the phone when the phone is idle. Enter the IP address
(for example, http://192.168.0.10 or 192.168.0.10 for IPv4; http://[2005:1:1:1:215:65ff:fe64:6e0a]
or [2005:1:1:1:215:65ff:fe64:6e0a] for IPv6) in the address bar of a web browser on your PC. The
default administrator user name and password are both “admin” (case-sensitive).
Note
The access to the Advanced settings of the Account or Network via web user interface may be
blocked by the web browser (for example, Chrome, Firebox) if you have installed “Adblock Plus
plugin”.
Downloaded from ManualsNet.com search engine

Yealink SIP-T40G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Wall mountable	Yes
Wi-Fi	No
Security algorithms	AES, HTTPS, SSL/TLS
Networking standards	IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP, TFTP, HTTP, HTTPS
Voice codecs	G.711, G.711a, G.711u, G.722, G.726, G.729ab
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.6 W
Certification	CE, FCC, ISO 9001
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Volume control	Digital
Display diagonal	2.3 \
Display resolution	132 x 64 pixels
Lines quantity	3 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	175 mm
Width	212 mm
Height	54 mm
