Yealink W56P User Manual

User Guide for the W56P IP DECT Phone
76
To transfer a call to another party when there are two calls on the handset via the
handset:
1. Place a call to user A.
2. Place another call to user B.
Two calls are established on the handset.
3. Select the desired call (e.g., the call with user A) and make sure the call is active.
4. Press the Options soft key, and then select Call Transfer.
The LCD screen displays the target party (user B) you will transfer the call to.
5. Press the Transfer soft key to complete the transfer.
The handset returns to the idle screen. Call is established between user A and User
B.
Note
You can create a conference with other two parties using the phone’s local conference.
The W56P IP DECT phones also support network conference.
Note
You can use the handset to create a local conference with other parties. The handset
supports up to 3 parties (including yourself) in a conference call. You can create a
conference between an active call and a held call on the handset (on the same line or
different lines).
To set up a local conference call via the handset:
1. Place a call to the first party.
2. Press the Options soft key, and then select Conference.
3. Do one of the following:
- Enter the number of the second party or select the handset you want to add to
the conference.
Press , , or the Conf. soft key to dial out.
- Press the Directory soft key, and then select the desired contact.
Press , , or the Call soft key.
Network conference is not available on all servers. For more information, contact your
system administrator.
The internal incoming call cannot be transferred.

Yealink W56P Specifications

General

Lines quantity	5 lines
Answering machine	Yes
Phonebook capacity	500 entries
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Standby time	400 h
Headset connectivity	3.5 mm
Ethernet LAN (RJ-45) ports	1
Voice codecs	CNG, G.711, G.711a, G.722, G.723, G.726, G.727, G.729, VAD, iLBC
Number of melodies	9
Volume control	Digital
Keypad number of keys	12
Number of function keys	6
Mounting	Desk/Wall
Handset type	Wireless handset
Product type	IP Phone
Product color	Black, Silver
Maximum indoor range	50 m
Maximum outdoor range	300 m
Dual-Tone Multi-Frequency (DTMF) modes	-
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Security algorithms	AES, MD5, SIPS, SRTP, SSL/TLS
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Fast Ethernet
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Battery technology	Lithium

Weight and Dimensions

Weight	7800 g
Package depth	196 mm
Package width	203 mm
Package height	95 mm
Package weight	8700 g
Base dimensions	153.5 x 108.5 x 45 mm
Handset dimensions (WxDxH)	175 x 53 x 20.3 mm
