Yealink W56P User Manual

Phone Settings
61
To delete a speed dial number via the handset:
1. Press to enter the main menu.
2. Select Settings->Telephony->Speed Dial.
The LCD screen displays all available speed dial keys.
3. Press or to highlight the desired speed dial key, which is already assigned a
number.
4. Press the Options soft key and then select Clear Key to delete the assigned speed
dial number.
To place a call using the speed dial key via the handset:
1. Long press the speed dial key (digit key 2-9) when the handset is idle.
The number assigned to this speed dial key is dialed out.
When auto answer feature is enabled, you can simply answer the incoming calls by
picking up the handset from the charger cradle without having to press the off-hook key.
The auto answer feature works only if the handset is placed in the charger cradle.
To configure auto answer via the handset:
1. Press to enter the main menu.
2. Select Settings>Telephony->Auto Answer.
3. Press the Change soft key to check or uncheck the Auto Answer checkbox.
Intercom is a useful feature in an office environment to quickly connect with the operator
or the secretary. You can make internal intercom calls and external intercom calls on the
phone. Internal intercom calls are made between handsets registered to the same base
station. External intercom calls can be made by dialing the feature access code
followed by the number. External intercom calls depend on support from a SIP server.
The handset can automatically answer an incoming external intercom call and play
warning tone only when there is only one handset subscribed and no call in progress on
the handset.
To automatically answer an incoming internal intercom call, you need to enable auto
intercom feature on the handset. The following configuration types of auto intercom

Yealink W56P Specifications

General

Lines quantity	5 lines
Answering machine	Yes
Phonebook capacity	500 entries
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Standby time	400 h
Headset connectivity	3.5 mm
Ethernet LAN (RJ-45) ports	1
Voice codecs	CNG, G.711, G.711a, G.722, G.723, G.726, G.727, G.729, VAD, iLBC
Number of melodies	9
Volume control	Digital
Keypad number of keys	12
Number of function keys	6
Mounting	Desk/Wall
Handset type	Wireless handset
Product type	IP Phone
Product color	Black, Silver
Maximum indoor range	50 m
Maximum outdoor range	300 m
Dual-Tone Multi-Frequency (DTMF) modes	-
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Security algorithms	AES, MD5, SIPS, SRTP, SSL/TLS
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Fast Ethernet
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Battery technology	Lithium

Weight and Dimensions

Weight	7800 g
Package depth	196 mm
Package width	203 mm
Package height	95 mm
Package weight	8700 g
Base dimensions	153.5 x 108.5 x 45 mm
Handset dimensions (WxDxH)	175 x 53 x 20.3 mm
